THE VIRGIN & CHILD

The Virgin who occupies the centre of the apse semi dome is represented enthroned with the Child seated in her lap. She rests her right hand on the Child's right shoulder, and her left, which holds a handkerchief, on the Child's left knee. The figure is complete except for an area of loss (roughly o.80 m. high and 0.70 wide) on the Virgin's left side corresponding to her left forearm and elbow, the Child's left hand, and part of the upper cushion placed on the throne. There is, furthermore, a fissure, caused by a structural crack in the shell of the semi dome, which runs down the middle of the figure to the apex of the central window. It is clear that the mosaic was executed at a time when the semi dome had already undergone the deformations it exhibits today.

With regard to the proportions of the figure, certain considerations ought to be borne in mind. The dimensions given below have been measured on the curve and show that, in general terms, the scale diminishes as one goes higher up the figure. This diminution, though not consistent (thus, the Virgin's feet are too small even by normal standards), is unmistakable: the Virgin's head is too small in relation to her total height (the proportion is 1: 8.3), her right hand is markedly smaller than her left hand, and the Child's figure, too, starting with rather large feet, loses scale towards the top. This anomaly cannot be explained by any rational attempt on the part of the artist to counteract optical distortion. Since the figure of the Virgin is placed above the windows of the conch, it lies, not as normally, on the quadrant of a circle, but in the upper half of a quadrant, and if we drew an imaginary line from the top to the bottom of the composition, this line would be at 300 to the horizontal. To see the mosaic at right angles from the ground one has to stand at the eastern end of the building, in line with the eastern exedrae. From the middle of the nave the top part of the mosaic is foreshortened more than its lower part, so that the proportion of head to body becomes about 1:9. It is only if one stands directly below the mosaic (a position inaccessible to the mediaeval worshipper) that the proportions become more nearly normal. In other words, the mosaic creator laid out the figure as if it were meant for the lower ring of a dome, to be viewed straight up, as, for example, in the Ascension dome of St. Sophia, Salonica, where the figures of the Virgin and apostles are correctly lengthened with relation to their heads. Note that in the apse of the latter church the head of the enthroned Virgin is, on the contrary, disproportionately big. What surely happened in our case is that the mosaic of the Virgin was designed from a platform more or less level with the windows of the apse semi-dome. If we suppose that the artist took his vantage point directly below the crown of the semi-dome or a very short distance further west, as he would have had to do in order to see the whole composition in one glance, then the proportions of the mosaic become reasonably normal, and, even more markedly, which was photographed from a point below the bema arch at the level of the marble cornice (proportion of head to entire body I:6.6).6 For further confirmation of our suggestion, note that in figure 12 the seat and footstool of the Virgin's throne appear nearly horizontal and the posts of the throne vertical, whereas when the mosaic is seen from below (cf. fig. I) the seat seems to sag in the middle and the posts to come apart at the base. In other words, the artist gave no thought to the appearance of the mosaic from the ground: he designed the composition free- hand and gave it the proportions which looked correct from his scaffold. Naturally, he could not have used any form of squared up sketch for transferring the design on to the wall.

The Virgin's Halo

The outline consists of four rows of red glass tesserae. The gold field of the halo is set concentrically, except for the trim round the head and shoulders which is three rows wide. Mixed with the gold cubes is a tiny proportion of silver ones. The underpainting on the setting bed is red.

The Virgin's Face and Neck

The eyebrows consist of a single row of black glass tesserae below which is a shadow line of purple-brown glass. The upper eyelids are in black glass, the lower eyelids in purple-brown glass. Whites of eyes: the lighted parts are of white limestone cubes, the shaded parts of olive glass. Pupils: the outline and centres are of black glass, the remainder of purple-brown glass. Intentional damage has been caused to both eyes perhaps by Fossati's workmen. The ridge of the nose consists of two vertical rows of fine-grained white marble, followed on the right (illuminated) side by one row of coarse-grained Proconnesian white marble and two rows of cream marble; on the left (shaded) side by one row of pink marble, one row of purple-brown glass, two rows of olive glass, and two rows of yellow-green glass. The tip, like the ridge, of the nose is in smooth white marble. The nostrils are of black glass, the dimple shadow under the nose is in purple-brown glass. The parting line of the mouth is in red glass. The upper lip, the high light on the lower lip and the corners of the mouth are in vermilion glass. The shadow under the mouth is in purple-brown glass.
The flesh tones are in the following materials: fine-grained white marble, Proconnesian white marble, milky off-white glass (used along the right edge of the face), cream marble and three shades of pink marble. There is a touch of vermilion glass on the tip of the chin, and three lines of it on the left cheek.
The shaded parts of the face consist of purple-brown glass, olive glass, light green, and yellow-green glass. The ears are not delineated. The tesserae used in the face are occasionally as small as 3 mm². There are small areas of loss on the forehead, under the right eye, and on the tip of the chin.
Under the chin there is a fairly heavy shadow in purple-brown glass and green glasses, the latter extending to the shaded (left-hand) side of the neck. There is, further, a line of light green glass at the base of the neck.

The Virgin's Right Hand

The lower line of the fingers and of the back of the hand is in red glass. The flesh tones are in fine-grained white marble, Proconnesian white marble, and three tones of pink marble; the shadows are in yellow-green glass. The knuckles on the index and middle fingers as well as the fingernails are imperceptibly indicated in fine-grained white marble. The nails are not outlined as in the left hand.

The Virgin's Left Hand and Handkerchief

The thumb and fingers are outlined on the spectator's right side with mat brown glass which also forms the heavy shadow on the back of the hand. The lighter shadow near the wrist as well as one line on the left side of the ring finger is in yellow-green glass. The flesh tones are the same as in the right hand. The nails are outlined in red glass.
Folded over the thumb is a handkerchief consisting of white Proconnesian marble, outlined on the spectator's left side with two rows of white limestone tesserae. Limestone is also used for the tasselled fringe on the left, but not on the right extremity of the handkerchief.

The Virgin's Feet

The feet, which are disproportionately small (the exposed part of the left foot being only 0.20 m long), are shod, as usual, in red slippers. Originally, the slippers were rendered in two tones: red glass was used for the shaded parts, while the lighted parts consisted of cubes dipped in red lead paint. The paint has largely flaked off, revealing both glass and stone tesserae of different colours, gold, silver, green, blue, etc.

The Virgin's Garments

The kerchief covering the Virgin's head is of white Proconnesian marble with a shadow line and sets of triple fold lines in turquoise glass. The kerchief is outlined against the face with a single line of black glass tesserae. The Virgin is dressed, as usual, in a stola and a maphorion. Both are of the same colour. The stola is visible below the neck, at the cuff of the right arm, and from the knees down. The stuff of the garments is indicated by means of only four shades of glass tesserae: turquoise, cobalt blue, dark blue, and black (at times pure black, at times purplish). The turquoise has undergone considerable surface deterioration causing it to turn a paler shade. This is especially noticeable at the Virgin's right knee, and produces, when viewed from a distance, the deceptive appearance of an exaggerated high light. The maphorion is adorned with cruciform segmenta, each consisting of four little gold squares; one of these ornaments is placed in the centre of the hood and one on each shoulder. The edge of the maphorion where it falls down from the left arm has a double edging in pale turquoise glass with the nigh lights indicated in white marble. Attached to the hem are tassels consisting of two or three threads tied in a knot. The tassels are rather schematically drawn; they are in white marble where they are against the blue of the maphorion and in blue glass where they are against the gold of the footstool.

The Child's Halo

The halo is outlined with three rows of red glass tesserae. The arms of the cross, which are nearly straight, are in white Proconnesian marble. The field of the halo is in gold, set concentrically. There is no admixture of silver cubes in the gold.

The Child's Head

There is intentional damage to the right eye. Further areas of loss occur above the right ear, at the top of the head, and down the left side of the hair to a point just above the left ear.

The Child is shown fair-haired. The lighter strands of hair are in yellow glass and yellow-green glass, the darker strands being in clear brown glass (gold cubes turned sideways) and mat brown glass. Accents are provided by occasional gold strands. A triple tuft falls over the middle of the forehead. The flesh tones of the face and neck are of the following materials. Fine- grained white marble is used for the projecting or high-lighted parts, viz. the centre of the forehead, above the eyebrows, one vertical row down the ridge of the nose and one transverse row across the top of the bridge, the tip of the nose, the top of the chin, and a few lines under the eyes. The grey vein of Proconnesian marble provides light shadows on the ridge of the nose (vertically, on either side of the white line), between the eyebrows, on the right side of the forehead (inside the green shadow line), under the eyes, and in a small patch to the left of the mouth. Three tones of pink marble are used, the palest mostly in the forehead, the two more intense tones in the cheeks and chin. Cream marble outlines the nose and nostrils. There are three tones of green glass: light yellow-green, yellow-green (under the eyes, on the right side of the neck, and on the right side of the forehead) and pale green (outline of the right jowl). Olive glass is used in two tones (one yellowish) to outline the entire left side of the head and in conjunction with purple-brown glass in the shadows round he eyes and under the mouth. Purple-brown glass outlines the nose and eyes.
The eyebrows, eyelids, nostrils, and corners of the mouth are in slightly purplish black glass. The parting of the mouth is in deep red glass. Vermilion glass is used in the lips, small spots on the cheeks, a spot on the bottom part of the chin, and others on the right ear. The whites of the eyes are in white limestone.

The Child's Right Hand

The right hand, which alone is preserved, is rather clumsily drawn. It is held in blessing, with the ring finger bent back and joined to the thumb. The spaces between the tips of the fingers have been left in unset plaster. The underside of the fingers and hand is outlined in deep red glass. The flesh tones are rendered by means of white marble, grey Proconnesian marble, and three shades of pink marble. The shadows are expressed in yellow-green and pale green glass.

The Scroll

The scroll, which was held in the Child's left hand, consists of a vertical strip, two to three rows of cubes wide, of mat white limestone; this is surrounded by two rows of Proconnesian white marble. The shadow line on the spectator's right is in two to three rows of pale turquoise glass, which also formed the circular opening at the top of the scroll.

The Child's Feet

The right foot, covered except for the toes and the lower part of the instep, is shown in head-on foreshortening. The left foot is in profile (length 0.34 m.). The feet are shod in sandals, the sole of which consists of a double row of gold cubes, and the thongs of one row of gold, bordered with clear brown glass. The flesh tones comprise fine-grained white marble, Proconnesian white marble, and three tones of pink marble. The shadow line along the sole of the left foot is in light yellow-green and yellow-green glass. The right foot has a green shadow line separating the toes from the instep.

The Child's Garments

As in the case of the Virgin, there is no distinction in colour between the tunic, of which the right sleeve and the portion covering the breast are visible, and the himation which envelops the rest of the body. The basic colour is gold. The high-lighted or forward parts are in silver, the shadows in mat brown glass. Darker fold lines are in transparent glass (gold cubes placed on their side), which is mostly brown, sometimes greenish.

THE THRONE

The throne on which the Virgin is seated is seen from the right and slightly from above. Owing to faulty perspective, its construction is not at once apparent. The horizontal seat is meant to be supported on two pairs of square posts, each pair being braced together by a cross-bar. The front post on the spectator's left has a ball base, but this is not the case with the rear post on the right. The right and left sections of the throne are differently proportioned (thus, the thickness of the seat is 0.2I to 0.245 m on the left and 0.32 on the right) and the cabochon stones decorating the respective parts do not line up. There are some further inconsistencies which will be described below.
The receding parts of the throne are made of a coarse granite which was originally of a brown colour, but has now paled to a grey of unsuitable shade. The granite tesserae are of varying sizes up to 2 cm long, and have been untidily set in horizontal rows, except in the cross-bar on the spectator's right, where they are set on the segment of a circle. Large and small tesserae have been used indiscriminately.
The horizontal seat of the throne is outlined on the spectator's left side with the same grey granite, except that about two-thirds of the upper outline are in three rows of mixed brown glass, mat and clear. On the spectator's right, the front and back outlines of the top of the seat are in clear brown glass, while the side of the seat and the lower front edge are outlined in granite.
The front of the seat is decorated with cabochon stones, alternately rectangular and oval. Between each stone are three pearls set in a vertical row. The stones, which are made alternately of green and red glass tesserae, have silver mounts outlined in brown glass. The pearls are of Proconnesian marble and have shadows of brown glass.
The left front post of the throne is outlined on the spectator's left with grey granite, except for the bottom 16 cm of the outline which is in brown glass. The decoration of the post consists of two oval and two rectangular stones and ten pearls. The oval stones red, the rectangular ones green. The mounts are, once more, silver, but they are outlined with granite cubes. The four top pearls have brown glass shadows, the four middle pearls shadows of grey granite, and the two bottom pearls blue glass shadows. Of the two bottom pearls, the one on the right is disproportionately big and its blue shadow cuts into the vertical outline of the post. The base of the post is outlined in dark blue glass.
The front post on the spectator's right is decorated with a red oval stone and a pair of green rectangular stones, as well as with pearls. As we have said, these stones do not line up with those on the left-hand post for the reason that the seat of the throne is considerably wider and comes lower on the right side than it does on the left.

THE CUSHIONS

Two cushions are placed on the seat of the throne. Although the Virgin is meant to be resting on them, the cushions give the impression of being laid behind her back. The upper cushion has its lighted parts in white Proconnesian marble. Light shadows are in grey Proconnesian marble, medium shadows in pale turquoise glass and heavy shadows in turquoise glass. The upper cushion is ornamented with ivy leaves in red glass tesserae. The greater part of this cushion on the spectator's right has been destroyed. The lower cushion has its high lights in yellow glass mixed with yellow-green glass. The main body of the cushion is in leaf-green glass, while medium shadows are in turquoise glass, partly decayed, and heavy shadows in dark blue glass.

THE FOOTSTOOL

The footstool is shown in reverse perspective and is placed to the right of centre with regard to the throne. The front of the footstool is 2.34 m long at the base; the height of the side increases from 0.33 m at the front to 0.365 m at the rear. The front, like the top of the footstool, is gold, whereas the side is shaded in mat brown glass with a sprinkling of gold cubes. The outline is in dark blue glass, the upper one of the front side being the heaviest (five rows wide). The lower horizontal and two vertical outlines of the front side are four rows wide, the lateral outlines three rows wide. The back of the footstool has no blue outline.
The front and side of the footstool are decorated with cabochon stones and pearls. The front has a diamond-shaped stone in the middle and three rectangular stones on either side; the side, an oval stone in the centre flanked by two rectangular stones. The mounts of the stones are gold with blue outlines. As on the throne, the stones are red and green alternately, but here there is an interesting refinement: some of the stones (the third, fifth, sixth, and seventh counting from the left) are in two tones of the same colour. In the case of red stones, the deeper tone is provided by red glass, the lighter by means of cubes of different colours that were dipped in red lead paint. In the case of green stones, leaf-green and blue-green glass provided the two tones needed. Observation of this segment of the mosaic makes it possible to determine the sequence in which the work was carried out. The figure of the Virgin and Child was made first. Secondly, the mosaic creator made the blue outline of the footstool, the tesserae of which conform to the lower line of the Virgin's stola. Thirdly, he bordered the upper and lower outlines of the front of the footstool with four horizontal rows of gold cubes. Next, he set the stones and pearls, working from right to left and from bottom to top: note that the mount of the central diamond-shaped stone is, for lack of room, amputated at the top, as are also the two one on each side of it.

THE GOLD BACKGROUND OF THE APSE SEMI-DOME

An irregular area of gold ground surrounding the Virgin and Child was set in the same bed of plaster as the figure. The limits of this area are indicated by a suture which is, for the most part, easily discernible. Anticipating our detailed observations on this suture, we may proceed to describe the probable sequence in which the mosaics of the semi dome were made. In the first place, the entire semi dome, roughly by the tops of the windows, was covered with a preliminary coating of plaster containing an appreciable proportion of chopped straw. Upon this first coating was laid a second thickness of plaster corresponding to the area intended for the figural composition and allowing sufficient room all round it. The setting bed of finer plaster was then applied, probably in smaller sections, although the boundaries between them cannot be traced. As usual, the artist proceeded to paint upon the setting-bed the subject of his composition, and in so doing he coloured yellow the background forming the immediate surround of the figure. The figural mosaic was then made, starting at the top and working downward. The composition turned out to be somewhat taller than originally envisaged, with the result that its lower extremity came to the very edge of the bed of plaster that had been laid and, incidentally, rather too close to the top of the central window. It may be observed that the rear right post of the throne came so close to the edge of the plaster that its corner had to be rounded off. Possibly, additional patches of plaster had to be added to accommodate parts of the composition, and this may explain some of the irregularities we have observed, e.g., the change in the material used for the outline at the lower extremity of the left-hand post of the throne. A trim of gold tesserae, two to four rows wide, was then made round the entire composition, after which the mosaic creator proceeded to cover with gold as much of the plaster bed as had been laid. He knew that the gold cubes had to be set on concentric curves, but he did not take the trouble of marking out exact setting-lines, with the result that he sometimes misjudged the direction of the lines and had to correct himself by inserting wedge-shaped patches of gold mosaic. After this process had been completed, the remainder of the conch was covered with a second, and then a third layer of plaster. This time the craftsman took a centre point immediately above the Virgin's head and probably using a long cord attached to a pin, marked out a number of concentric semicircles. A small area of loss to the south of the composition and more or less level with the Child's head has enabled us to ascertain that these guide-lines were indicated in red paint upon the second coat of plaster. The over-all, gold background was laid with the help of these guide-lines, but with the inevitable result that the rows of tesserae did not exactly line up with those in the gold ground belonging to the immediate surround of the figure.
The average size of the cubes used in the background is 5 to 6 mm², and there are roughly 225 of them per 10 cm². Mixed with the gold is an appreciable proportion of silver tesserae. This admixture is least in the immediate surround of the figure and more considerable in the over-all back- ground, but there is no consistency about the proportion of silver, which in places is as much as 10%, in others almost nil. In addition to the silver, there is also a sprinkling of red glass cubes in the over-all background, a peculiarity we have also observed in the mosaic of St. Ignatius Theophoros in the north tympanum. The underpainting on the setting-bed of the over-all gold background (as distinct from that of the gold surround of the figure) is red.

THE INSCRIPTION

The face of the apse semi dome was occupied by an inscription commemorating the restoration of religious images after the defeat of Iconoclasm. The full text, preserved in the Palatine Anthology was as follows: The images which the impostors had cast down here pious emperors have again set up. Today, only the very beginning and end of the inscription remain. The same letters were uncovered by the Fossati brothers in 1847 - 49, whose record of them is, however, rather confused. The identification of the preserved fragments with the distich in the Anthology is due to Antoniades. The inscription was written in capital letters 0.40 m high on a gold band 0.54 to 0.57 m wide. The letters are in dark blue glass. The background is gold with a small admixture of silver, set in widely spaced rows of angled tesserae, as was often done on vertical surfaces. The setting-bed under the gold was painted yellow.

THE GARLAND BORDERS

Sumptuous garland borders were placed on either side of the commemorative inscription (i.e., one running round the soffit of the bema arch along its eastern edge, the other convex and folded over the rim of the apse semi-dome), along the base of the apse semi-dome, and under both archangels at the springing of the bema arch: roughly seventy running meters in all, of which about forty-four are preserved, either entirely or in part. Furthermore, a similar garland border at a somewhat smaller scale, and again convex, folds round the interior edges of the five windows of the apse, totaling about thirty-one running meters.
The garland borders are delimited by a double outline normally consisting of three rows (two round the windows) of terracotta tesserae or marble tesserae dipped in burnt umber paint, and of two rows of white marble tesserae. Within this outline the background is gold with an admixture of silver cubes. The garland itself consists of a dark blue sheaf bordered on either side with a row of green bay leaves. The leaves are inclined in the direction in which the garland is proceeding, and the tips of the leaves are, here and there, bent over backwards. Round the blue sheaf is twined spirally a silver (occasionally white marble) ivy vine. Attached to this vine, in addition to normal spade-shaped leaves, are five-petal flowers, clusters of berries, and pears, all usually in silver. The space between each turn of the vine is filled with a variety of vegetal motifs, to wit, curving stems bearing pomegranates, pears, and circular flowers on short straight stems. The pears and flowers are usually arranged in rows of three. In the intervening spaces are sprinkled circular berries, either red or gold.
Wherever the garland has to turn at a right angle, it is contained in a kind of L -shaped tube which gives the appearance of being made of silver. The rotundity of this tube is indicated by parallel bands of colours, usually white limestone or marble in the middle, shading off on either side first to silver, then to turquoise, then to dark blue. The ends of the tube are folded over, and there is a two-tone red ribbon twined round the tube. If we conceive the garlands as proceeding out of these corner tubes, there is a centre point at which two converging garlands meet. This point is occupied by a star-shaped flower, such as the one directly under the south archangel. Another, incompletely preserved, flower remains at the apex of the bema arch. The flower under the archangel has a centre of turquoise glass, four trefoil petals in red glass and terracotta, and four pointed gold petals. A similar flower occupies the apex of each of the five windows of the apse.
The window borders are of similar design, except that the horizontal band at the base of the windows, being only about 0.25 m wide, has the sheaf without the green leaves. In windows 2 and 3 it is clearly seen that the vertical bands of border were made first and the horizontal band next on a separate bed of plaster, with a straight joint on either side.
Given the considerable length of the garland borders, it is only natural that we should encounter in them some differences of detail. The most carefully executed stretch is at the base of the apse semi-dome, between windows 1 and 3. The length of border between window No. 1 and the face of the apse is of somewhat looser construction: the round flowers and pears (which here have long stems) are not lined up, as elsewhere, in neat vertical rows, and there are no pomegranates. In spite of such inconsistencies, there is an undeniable uniformity both of technique and materials in all of the garland borders. Especially noticeable is the extensive use throughout the garlands and always in the same contexts of painted tesserae. In addition to the red and white outline, these occur in the ribbons that are looped round the corner tubes, in the pears, the pomegranates, the stems and in the small round berries. The latter appear to have been further touched up with red lead paint, as is also the case with the feet of the south archangel.



This text is from The Apse Mosaics of St. Sophia at Istanbul. Report on Work Carried out in 1964 Author(s): Cyril Mango and Ernest J. W. Hawkins
Author(s): Cyril Mango and Ernest J. W. Hawkins
